PAS68 Pedestrian Railing System – CR830PR
The CR830PR is a shallow 400mm foundation pedestrian railing system. This bollard is manufactured and delivered complete with integral re-bar cage, making this the easiest product to install – no continuous trenching required. It was tested with the N2 7,500kg vehicle at 48kph.
Technical Specifications
- PAS68 V/7500[N2]/48/90:1.5/0.0
- Railing tested at 3000mm span (7,500kg vehicle at 48kph)
- Bollard Diameter: 193mm
- Rail Diameter: 100mm
- Height: 950mm to top of rail
- Optional Finishes: Hot dip galvanised (HDG), powder coated, wet painted, stainless steel
- Foundation: 1400mm W x 1150mm x 400mm shallow depth
- No continuous trenching required
- Uprights are set 3 metres apart by 100mm crossbars
- Cross bars are fully independent and can be completely removed within minutes to allow vehicle access
- Each upright is supplied as per the world famous ‘Bollard in a box’ meaning that no additional rebar of any sort is required
